Complete SOLIS GO Portable WiFi Hotspot User Guide
📱 SOLIS GO User Guide
Your complete guide to the ultimate 2-in-1 travel companion. Stay connected anywhere with WiFi hotspot and power bank functionality.
📋 Quick Navigation
✨ Key Features
🌐 WiFi Hotspot
Connect up to 5 devices simultaneously with 3G/4G internet via vSIM technology.
🔋 Power Bank
Built-in battery with Type-C and Lightning cables to charge your devices.
📊 LED Indicators
Clear visual feedback for cellular, data, WiFi, and battery status.
🔌 Flexible Charging
Type-C port, built-in Type-A cable, or Kiosk charging pins.
🚀 Quick Start
Get Connected in 3 Easy Steps:
1 Power On: Press and hold power button for 3 seconds
2 Wait: All three signal LEDs will become solid (1-3 minutes)
3 Connect: Find SSID and password on device, connect via WiFi
⚠️ General Safety Instructions
- ✓ Make sure the SOLIS GO device is fully charged prior to use.
- ✓ Under condition of low battery, the LED lights will turn off while charging a device. Recharge the SOLIS GO device as soon as possible to avoid shortening the battery life.
- ✓ The battery should be charged at least every three months to avoid shortening the battery life.
- ✓ It is recommended to disconnect a fully-charged device to avoid unnecessary battery use.
- ✓ Keep the SOLIS GO device away from fire and avoid temperatures above 70°C when not in use or 55°C when in use.
- ✗ Do not get SOLIS GO device wet or immerse it in water.
- ✗ Do not wash SOLIS GO device with corrosive cleaner.
- ✗ Do not squeeze or puncture SOLIS GO device so as to avoid electrolyte leakage of lithium-ion battery.
- ✗ Do not attempt to disassemble, modify or fix SOLIS GO device.
- ✗ Do not use a damaged cable or power charger to charge SOLIS GO device.
📶 Using WiFi Hotspot
Power On
Press and hold the button on the front for 3 seconds to turn on.
Connecting to Internet
- Device automatically connects to Internet with vSIM
- Takes 1-3 minutes depending on network/location
- All three signal LEDs become solid when connected
- If not connected after 5 minutes, restart device
WiFi Setup
- Go to "Network Settings" and turn on WiFi
- Find SSID printed on device front
- Enter password from device
Power Off
Press and hold button for 3 seconds to turn off.
🔋 Using Power Bank
- Pull out cable (Lightning for iOS, Type-C for Android)
- Plug into your device
- Press charge button to activate power bank mode
- 4 battery LEDs show remaining power
- Remove cable to stop charging
⚡ Charging SOLIS GO
Method 1: Built-in Cable
- Pull out Type-A cable by sliding down
- Plug into USB charger or computer
- 4 LEDs show charging status
- All 4 white LEDs = 100% charged
Method 2: Your Own Cable
- Connect Type-C port (on device side) to charger
- All 4 white LEDs = charging complete
🔍 Components Reference
Component locations - refer to numbered diagram
| No. | Component | Status/Type | Function |
|---|---|---|---|
| 1 | Cellular LED | ⚪ White Solid | Connected to vSIM network |
| 💫 White Blinking | Connecting to signal | ||
| ⚫ Unlit | Cellular off or Error | ||
| 2 | Data Transfer LED | ⚪ White Solid | Data transfer available |
| 💫 White Blinking | Data transferring | ||
| ⚫ Unlit | Data not available | ||
| 3 | WiFi LED | 💫 White Blinking | Booting up, WiFi not ready |
| ⚪ White Solid | WiFi ready | ||
| ⚫ Unlit | WiFi not available | ||
| 4 | Power Button | Press 3 seconds | Turn on/off device |
| 5 | Battery LED | 🔋🔋🔋🔋 4 LEDs | More than 75% |
| 🔋🔋🔋 3 LEDs | 50%–75% | ||
| 🔋🔋 2 LEDs | 25%–50% | ||
| 🔋 1 LED | 10%–25% | ||
| ⚠️ 1 LED Blinking | Less than 10% - Charge soon! | ||
| 6-7 | Charging Cables | ⚡ Lightning cable | Charge iPhone/iPad |
| ⚡ Type-C cable | Charge Type-C devices | ||
| 8 | Type-A Cable | Built-in cable | Charge in SOLIS GO |
| 9 | Type-C Port | Input port | Charge SOLIS GO |
| 10 | Charging Button | Press button | Start power bank mode |
| 11 | Charging Pins | Contact pins | Charge in Kiosk |
| 12 | WiFi Information | SSID + Password | Network credentials |
| 13 | QR Code | Consumer Portal | Scan to access portal |
🛠️ Troubleshooting
❌ No Internet
Restart device after 5 minutes. Check cellular coverage.
🔋 Battery Draining
Don't charge SOLIS GO while using as power bank.
📶 WiFi Not Showing
Wait for WiFi LED (#3) to show solid white.
⚡ Not Charging
Check cables. Try both Type-A cable and Type-C port.
📊 Technical Specifications
📱 General Information
| Product Name | Solis Go |
| Dimensions | 150 × 67 × 17.5 mm (L × W × H) |
| Weight | 180g |
| Case Material | Plastic, Dark Blue |
⚙️ Hardware & System
| CPU | MediaTek MT8766 4×A53 @ 2.0GHz |
| Memory | 1GB RAM + 8GB ROM |
| Operating System | Android 10 |
| SIM Card | Virtual SIM (vSIM) |
📡 Network & Connectivity
| 4G Bands | B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/B20/B25/B26/B28A/B28B/B29/B30/B34/B38/B39/B40/B41/B66/B71 |
| 3G Bands | B1/B2/B4/B5/B8 |
| LTE Category DL | Cat.7 (300 Mbps max) |
| LTE Category UL | Cat.13 (150 Mbps max) |
| 4G Antenna | MIMO 2×2 |
| WiFi | 802.11 a/b/g/n/ac Dual Band (2.4GHz & 5GHz), Single Active |
🔌 Ports & Interfaces
| Output Cables | 1× USB-C cable 1× Apple Lightning cable |
| Input Cable | 1× USB-A cable (built-in) |
| USB Port | Type-C, USB 2.0 |
| Buttons | 1× Power Button 1× Charging Button |
| LED Indicators | Power, Cellular, Data, Wi-Fi |
🔋 Battery & Power
| Battery Capacity | 8000mAh lithium polymer |
| Power Input | 5V / 2A |
| Power Output | 5V / 1A |
🌡️ Environmental & Safety
| Working Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -20°C ~ 70°C (-4°F ~ 158°F) |
| Humidity | 10% ~ 90%, non-condensing |
| Drop Resistance | 1 meter |
| Certifications | FCC, CA65, CE, ROHS, REACH, WEEE, RCM, UN38.3 |
🎯 Conclusion
SOLIS GO is your perfect travel companion, combining WiFi hotspot and power bank in one compact device. Stay connected and charged wherever you go.
💡 Pro Tips
✓ Keep firmware updated
✓ Charge fully before trips
✓ Store in cool, dry place
✓ Clean ports regularly
✓ Avoid extreme temperatures
